Thru Hole Silicon Bridge Rectifier, WOM Series, 2W10 Type, 4 Pins, Reverse Voltage 1000V Max. Forward Current 2A Max.
Thru Hole Silicon Bridge Rectifier, WOM Series, 2W10 Type, 4 Pins, Reverse Voltage 1000V Max. Forward Current 2A Max.
• The plastic package carries Underwrite Laboratory Flammability Classification 94V-0
• Low reverse package
• High forward surge current capability
• High temperature soldering guaranteed: 260°C /10 second, 5 lbs.(2.3kg) tension
APPLICATION
• For printed circuit board
| Series | WOM |
|---|---|
| Part Status | Active |
| Supplier Device Package | WOM series, 4Pins |
| Repetitive peak reverse voltage | 1000Volts |
| RMS voltage | 700Volts |
| DC blocking voltage | 1000Volts |
| Average forward rectified current at Tc= 55°C | 2.0A |
| Peak forward surge current 8.3ms single half sine-wave superimposed on rated load(JEDEC Method) | 50A |
| Rating for Fusing (t<8.3ms) | 10A²S |
| Forward voltage drop per bridge element at 7.5A | 1.0Volts |
| Junction capacitance | 15pF |
| Operating junction temperature range | -55°C ~ +125°C |
| Mounting Type | Surface Mount |
| Package / Case | WOM Series, 2W10 Type 4 Pins |
| RoHS Status | RoHS III Compliant |
| Moisture Sensitivity Level (MSL) | 1 (Unlimited) |
| REACH Status | REACH Unaffected |
| HTSUS | 8541.21.0075 |
| Standard Package (MPQ) | 1000pcs/Box, Quantity entered must be multiple of 1000 |
| NCNR | Non-Cancelable/Non-Returnable |
